XCMG Drilling Rig XR150DIII

Latest version of classic XR150D series rotary drilling rig...

XCMG Drilling Rig XR150DIII

1

2

Main Features
1、It adopts the dedicated hydraulic retractable crawler chassis and large diameter slewing bearing to provide extraordinary stability and transport convenience.

2、It adopts the Cummins electric control turbo-supercharged engine to provide strong power and conformity with Euro III emission standard.

3、With the hydraulic pressure system adopted threshold power control and negative flow control,the system acquired high efficiency and higher energy conservation.

4、Using single rope winding, effectively solve the steel wire rope wear problem, improve the life of wire rope; And drill deep detection device is setted in main winding,single rope to make deep inspection more accurate.

5、The whole machine design meet the requirements of the CE directive, safety guarantee, construction safer.

6、The optional centralized lubrication system, maintenance more convenient.

7、Several drilling rod configurations with different specification are available for efficient construction on different layers.

8、The detachable unit head drive key can provide easy maintenance and replacement.

Description

Unit

Parameter value


Max. drilling   diameter

mm

1500




Max. drilling   depth

m

56


Allowable   luffing scope (from center of drill rod to slewing center)

mm

32503650


Drilling rig   dimension in working condition (L × W × H)

mm

7550×4200×19040


Drilling rig   dimension in transport condition (L × W × H)

mm

13150×2960×3140


Weight of   overall unit (standard configuration, excluding drilling tool)

t

49


Engine

Model


CUMMINS    QSB7


Rated   power/speed

kW

150/2050r/min


Max. working   pressure of hydraulic system

MPa

35


Rotary drive

Max. torque

kN •m

150


Rotational speed

r/min

733


Crowd    cylinder

Max. Pushing   force

kN

120


Max. Pulling   force

kN

160


Max.stroke

mm

3500


Main winch

Max.pulling   force

kN

160


Max. single-rope   speed

m/min

72


Diameter of the   steel wire rope

mm

26


Auxiliary winch

Max.pulling   force

kN

50


Max. single-rope   speed

m/min

60


Diameter of the   steel wire rope

mm

16


Drilling mast

Left/right   inclination of mast

°

3/3


Front/back   inclination of mast

°

5/15


Rotary table   slewing angle

°

360


Traveling

Max. traveling   speed of the overall unit

km/h

2.1


Max. climbable   gradient of the overall unit

%

40


Crawler

Width of crawler   plate

mm

700


External width   of crawler (min.-max.)

mm

29604200


Center distance   between two longitudinal wheels of crawler

mm

4310


Average ground   pressure

kPa

83
