Power System
The installed CUMMINS engine, featuring strong power, high efficiency and energy-saving, and low maintenance cost.
The rated power reaches 257kW, featuring high torque reserve coefficient.
The radially sealed intake system is applied to effectively prolong the engine life.
Drive system
The curves of drive system and engine are perfectly matched to achieve more extensive high-efficiency zone and higher transmission efficiency.
Shantui’s self-made drive system features stable performance and reliable quality and has been long proved by the market.
Driving/Riding Environment
The hexahedral cab provides super-large interior space and broad vision and the ROPS/FOPS can be installed depending on specific needs to ensure high safety and reliability.
The electronic control hand and foot accelerators guarantee more accurate and comfortable operations.
The intelligent display and control terminal and the A/C and heating system are installed to provide more abundant personalized driving/riding experience and enable you to understand system status at any time, featuring high intelligence and convenience.
Working adaptability
Shantui’s stable and reliable chassis system is applicable to diversified severe working conditions.
The product features long ground length, high ground clearance, stable driving, and good trafficability.
The straight tilting blade, semi-U blade, angle blade, coal blade, rock blade, environmental sanitation blade, ripper, and traction frame can be installed depending on specific working condition to achieve higher working adaptability. The standard LED working lamps improve the illumination capability during nighttime operations to achieve higher safety and reliability.
Parameter name | SD32 (Standard version) |
Performance parameters | |
Operating weight (Kg) | 40200 |
Ground pressure (kPa) | 97.7 |
Engine | |
Engine model | WP12/QSNT-C345 |
Rated power/rated speed (kW/rpm) | 257/2000，258/2000 |
Overall dimensions | |
Overall dimensions of machine (mm) | 8650*4130*3760 |
Driving performance | |
Forward speed (km/h) | F1:0-3.6 F2:0-6.6 F3:0-11.5 |
Reversing speed (km/h) | R1:0-4.4 R2:0-7.8 R3:0-13.5 |
Chassis System | |
Center distance of track (mm) | 2140 |
Width of track shoes (mm) | 560/610/660/710 |
Ground length（mm） | 3150 |
Tank capacity | |
Fuel tank (L) | 640 |
Working device | |
Blade type | Straight tilting blade , Angle Blade and Semi-U blade |
Digging depth (mm) | 560/630/560 |
Ripper type | Single-shank three-shank |
Ripping depth (mm) | 1,250 (Single-shank) and 842 (Three-shank) |
