More excellent performance
• The optimizing layout of the machine makes the stress of the main bearing carriers more reasonable, and the lifting performance is higher than the products with the same tonnage.
• Apply the mature jib technique which integrates plug-in boom head, embedded boom block, and special telescoping mechanism, which makes the jib more stable and reliable.
• Optimize the stress design. Adopt the box-type outriggers which have larger span, stronger rigidity, and better stability.
More reliable quality
• Adopt the classic K series jib telescoping technique, working safer and more reliable.
• Make the most complete safety device system in the industry, ensuring the lifting safer and more reliable.
• The comprehensively upgraded brake system adopts double circuit air pressure design. Multiple systems ensure the brake safety of the truck during travel.
• The new power steering mechanism adopts hydraulic power design, which makes the steering light, flexible, and precise, and ensures the safety of the truck.
• The intensity and rigidity of the rotary table and frame structure with high rigidity are completely coordinated.
• The perfect integration of the design and structure realizes the automation of welding, which is more reliable.
Easier to operate
• The high efficient and energy efficient load sensing hydraulic system is sensitive to operate and precise to control, having good slight mobility.
• Optimize the control levers, which is easier to operate.
• The cab adopts orthodrome front windscreen, having wider operating views.
Dimension | Unit | XCT25L5 |
Overall length | mm | 12870 |
Overall width | mm | 2550 |
Overall height | mm | 3470 |
Weight | ||
Total weight in travel | kg | 33000 |
Power | ||
Engine model | SC9DF290.1Q4/SC9DF290.2Q4 | |
Engine rated power | kW/(r/min) | 213/1900 |
Engine rated torque | N.m/(r/min) | 1400/1400 |
Travel | ||
Max. travel speed | km/h | 90 |
Min. turning diameter | m | 21 |
Min. ground clearance | mm | 260 |
Approach angle | ° | 12 |
Departure angle | ° | 14 |
Max. grade ability | % | 45 |
Fuel consumption for 100km | L | 30 |
Main performance | ||
Max. rated total lifting capacity | t | 25 |
Min. rated working radius | m | 3 |
Turning radius at turntable tail | m | 3.34 |
Max. lifting torque | kN.m | 1132 |
Base boom | m | 10.2 |
Max.main boom | m | 41 |
Max.main boom+jib | m | 50.2 |
